STONEX R2 User Manual

STONEX R2
113
⑤Press to select the base points
of extended point and the point
related to horizontal distance, i.e. to
decide whether the horizontal distance
is the distance between extended point
and start point or end point.
【Extention】
Define Extention!
Point 1： 20
Point 2： 22
H-Dist : 20.000 m
Select Base Pt!
Base Pt： 20 AB
MEAS CALC SEARCH ↓
⑥Press [F2] (CALC) to display the
result.
To stake out this point, input new PtID,
and press [F1] to start staking out .‴2)
To save the data, press [F4].
To quit the result menu, press [ESC] to
return to data inputting menu, and
re-input the data.
[F2]
【COGO New Point】
New Point：
X/N ： 20.000 m
Y/E ： 25.000 m
STAKE RECORD
‴1) There are four methods to input the known PtID. Please refer to step ② of the last section
“5.8.1.1Traverse”.
‴2) The stake-out operation of is similar to that of Traverse, which has been introduced previously.
Please refer to “5.8.1.1 Traverse”.
5.9 TIE DISTANCE
The application Tie Distance computes slope distance, horizontal distance, height difference
and azimuth of two target points measured online, selected from the internal memory or entered
manually.
User can select between two different methods:
[F1] Polygonal (A-B, B-C)
[F2] Radial (A-B, A-C)
5.9.1 Polygonal (A-B, B-C)
