4.8 TRACKING
Switch on or off the tracking measurement mode. The new setting is displayed for
approximately one second and then set. The function can only be activated from within
the same EDM type and prism type.
OPERATIONAL STEPS
OPERATION
DISPLAY
①Press soft key [FNC] to enter into
Function menu. Press [PAGE] twice to
turn to Page 3.
FNC
+
PAGE
【 FUNCTION 】 3/4
F1 EDM Tracking (9)
F2 Light ON/OFF (0)
F3 Laser Pointer On/Off
② Press [F1] to activate tracking
function. Screen displays as the right
picture. To deactivate tracking
function, just enter into Function menu
and press [F1] that sets the EDM
Tracking again.
Open Tracking Mode！
Every time when pressing the soft key that sets EDM Tracking function, the measurement
mode will switch between Fine [s] and Tracking.
The last active measurement mode remains set when the instrument is switched off.
5. PROGRAMS
APPLICATION PRE-SETTINGS
There are programs that precede the application programs and are used to set up and
organize measurement station data. They are displayed after selecting an application.
Users can select the start programs individually.
[*]: Settings made.
[ ]: Settings not made.
【Setting Meas】
[ * ]F1 Setting Job (1)
[ ]F2 Setting Station (2)
[ ]F3 Set Orientation (3)
F4 Start (4)
