184
③Press [F1] to start V-Index
Adjustment. The screen displays as the
right graph:
[F1]
【V-Index】
<Step 1> Front
HR： 219°17′58″
V ： 94°05′12″
Sight the target！
MEAS .
④In Face I, precisely collimate target
A and press [F1] (MeaS).
Collimate the
target
+
[F1]
【V-Index】
<Step 2> Reverse
HR： 39°11′05″
V ： 265°54′15″
Sight the target！
MEAS .
⑤ Rotate the telescope, and collimate
the same target precisely in Face Ⅱ.
Press [F1] (Meas). When setting is
finished, the screen displays as the
right graph.
Collimate the
prism in
reverse
position
+[F1]
【V-Index】
Index Difference： 3°58′11″
VT Error： 0°00′31″
BACK SET
⑥Press [F4] (set) to finish V-Index
Adjustment. The screen returns to the
Adjustment menu.
[SET]: Replace old adjustment value
with the new one.
[ESC] ： Quit the program without
saving new adjustment value.
[F4]
【Adjustment】 ▼
F1 V-index (1)
F2 Hz-collimation (2)
F3 Horizontal Axis (3)
F4 VO/Axis(Cons.list) (4)
Note:
1. Repeat the checking steps to measure the Index Difference (i angle). If the Index
If difference cannot meet the requirement, user should check whether the three steps of
the adjustment and the collimation are right. Then set again according to the requirement.
2. If Index Difference still not meets the requirement after the repeated operation, the
instrument should be returned to factory for inspection and repair.
13.7 TRANSVERSE AXIS ERROR COMPENSATION ADJUSTMENT
As the transverse axis error only affects the angle of sight, it can be only confirmed
through observing the target the height of which is obviously lower or higher than the
instrument.
To avoid the influence of sight axis, user must have an associated adjustment before
adjusting sight axis.
