STONEX R2 User Manual

STONEX R2
185
It is unnecessary to collimate the prism or the target plane to ascertain the transverse axis
error. Therefore user is enabled to launch this adjustment at any time. Select a
recognizable point which is rather far away from the instrument, and much higher or
lower than the instrument. Make sure it can be precisely collimated twice.
STEP：
OPERATIONAL STEPS
OPERATION
DISPLAY
①Press [F3] to Horizontal Axis in
Adjustment function.
[F3]
【 Adjustment】 ▼
F1 V-index (1)
F2 HZ-collimation (2)
F3 Horizontal Axis (3)
F4 VO/Axis(Cons.List) (4)
②The screen shows as the right graph:
In Face I precisely collimate target
(obliquity is ±10°~±45°), press [F1]
(Meas) 10 times.
Collimate the
target in
normal
position
+
[F1]10 times
【Horizontal Axis】 [0/10]
<Step 1> Front
HR： 335°28′41″
V ： 107°16′20″
Please sight the target！
MEAS INPUT
③Rotate the telescope, and collimate
the same target precisely in Face Ⅱ.
Press [F1] (Meas) 10 times.
Sight the
prism in
reverse
position
+[F1]
10 times
【Horizontal Axis】 [0/10]
<Step 2> Reverse
HR： 155°27′01″
V ： 252°43′47″
Please sight the target！
MEAS INPUT
④When finishing setting, the screen
shows as the right graph.
【Transverse Axis Error Adjustment】
Transverse Axis Error： 0°00′36″
BACK SET
⑤Press [F4] (set) to finish Index
Difference Adjustment. The screen
returns to the ADJUSTMENT menu.
[SET]: Replace old adjustment value
with the new one.
[ESC]: Quit the program without
saving new adjustment value.
[F4]
【 Adjustment】 ▼
F1 V-index (1)
F2 HZ-collimation (2)
F3 Horizontal Axis (3)
F4 VO/Axis(Cons.List) (4)
