STONEX R2 User Manual

STONEX R2
105
return to data inputting menu, and
re-input the data.
‴1) There are four methods to input the known PtID. Please refer to step ② of the last section
“5.8.1.1Traverse”.
‴2) The stake-out operation is similar to that of Traverse, which has been introduced previously. Please
refer to “5.8.1.1 Traverse”.
5.8.2.3 Distance-Distance Intersection
The known data:
P1 The first known point
P2 The second known point
r1 Radius, as defined by the distance from P1 to P3 or P4
r2 Radius, as defined by the distance from P2 to P3 or P4
The unknown data ：
P3 The first COGO point
P4 Second COGO point
OPERATIONAL STEPS
OPERATION
DISPLAY
①In Intersections menu, press [F3]
to enter into Distance- Distance
Intersection function.
[F3]
Intersections
F1 Bearing-Bearing
F2 Bearing-Distance
F3 Distance- Distance
F4 By Points
