STONEX R2 User Manual

STONEX R2
104
OPERATIONAL STEPS
OPERATION
DISPLAY
①In Intersections menu, press [F2]
to enter into Bearing-Distance
Intersection function.
[F2]
【Intersections】
F1 Bearing-Bearing
F2 Bearing-Distance
F3 Distance- Distance
F4 By Points
②Input PtID of the known P1 point,
and press [ENT] to move to next
item. ‴1).
Input PtID1
+
[ENT]
【Bearing-Distance】
Input data!
Point 1： 10
AZ : ---°---′---″
Point 2： ---
H-Dist： ---.--- m
MEAS CALC SEARCH ↓
LIST ENH |←
③Input azimuth from P1 to unknown
points P3 and P4, and press [ENT] to
move to next item.
Input
azimuth
+
[ENT]
【Bearing-Distance】
Input data!
Point 1： 10
AZ : 45°00′00″
Point 2： ---
H-Dist： ---.--- m
MEAS CALC SEARCH ↓
LIST ENH ∣←
④Input PtID of another known point
P2. Repeat step ②.
Input PtID2
+
ENT]
【Bearing-Distance】
Input data!
Point 1： 10
AZ : 45°00′00″
Point 2： 11
H-Dist： ---.--- m
MEAS CALC SEARCH ↓
LIST ENH ∣←
⑤ Input horizontal distance between
P2 and P3 or P4, and press [ENT].
Input HD
+
[ENT]
【Bearing-Distance】
Input data!
Point 1： 10
AZ : 45°00′00″
Point 2： 11
H-Dist： 2.000 m
MEAS CALC SEARCH ↓
LIST ENH ∣←
⑥ Press [F2] (CALC)to display the
result.
To stake out this point, input new PtID,
and press [F1] to start staking out .‴2)
To save the data, press [F4].
To quit the result menu, press [ESC] to
【COGO New Point】
New Point ： --- --- ---
X/N ： 114.142 m
Y/E ： 114.142 m
New Point 2： --- --- ---
X/N ： 85.858 m
Y/E ： 85.858 m
STAKE RECORD
