52
Temp. Unit
‵ / ℉
²‵ Degree Celsius
²℉ Degree Fahrenheit
Press Unit
hPa/mbar/mmHg/in
Hg
²hPa Hecto Pascal
²mbar Milliba
²mmHg Millimeter mercury column
²inHg Inch mercury column
Code Rec.
Save before /
Save after
Sets if the code block is saved before or after the
measurement (see “3.3.4 Coding”)
GSI 8/16
GSI 8/ GSI 16
Select GSI output format.
GSI 8: 81..00+12345678
GSI 16: 81..00+1234567890123456
Mask1/2
Mask1/ Mask2
Select GSI output mask.
²Mask1：PtlD, Hz, V, SD, ppm+mm, hr, hi
²Mask2：PtlD, Hz, V, SD, E, N, H, hr
4.5 HEIGHT TRANSFER
This function determines the height of the instrument from measurements to a maximum
of 5 target points with known heights, in two faces.
While measuring to several targets with known heights, the improvement is indicated in
the “delta” value.
OPERATION STEPS：
OPERATIONAL STEPS
OPERATION
DISPLAY
