Beep
ON/OFF
The beep is an acoustic signal after each key stroke.
ON: Beep switched on.
OFF: Beep switched off.
HZ <=>
Right Ang / Left
Ang
HZ Incrementation Direction:
Right Ang: Set right HZ for “clockwise direction
measurement”.
Left Ang: Set left HZ for “Counter-clock direction
measurement”.
FaceⅠ Def.
VK-Left/
VK- Right
Defines the telescope face I in relation to the position of
the V circle.
Data Output
Intern / RS232
²Intern: All data is recorded in internal memory.
²RS232: Data is recorded via the serial interface. With
this aim, a data storage device must be connected.
Auto - OFF
ON/OFF
²ON: The instrument is switched off after 20 minutes
without any action (= no key pressed; V and HZ angle
deviation <3‟/+600cc).
²OFF: The instrument is switched on permanently. Battery
discharges quicker.
Min Reading
The displayed angle format can be selected in three
grades.
²For 360° ′ ″: 0°00′01″/0°00′05″/0°00′10″
²For 360°: 0.0001°/0.005°/0.0010°
²For gon: 0.0001gon/0.0005gon/0.0010gon
²For mil: 0.01mil/0.05mil/0.10mil
Angle Unit
dd. mm. ss
/ deg/ gon/ mil
²° ′ ″(degree, sexagesimal), possible angle values: 0°~
359°59′59″
²DD(degree, decimal), possible angle values:0º~359.9999º
²gon, possible angle values：0gon~399.9999gon
²mil, possible angle values：0mil~6399.99mil
The setting of the angle units can be changed at any time.
The actual displayed values are converted according to the
selected unit.
Dist. Unit
Meter / US-ft /
INT-ft / ft – in 1/8
²M Meter
²US-ft Us-feet
²INT-ft International feet
²ft-in 1/8 US-feet-inch-1/8 inch
