STONEX R2
50
TriggerKey
All/ Dist/OFF
The trigger key is right above the Power Key.
OFF Trigger key deactivated.
All Trigger key with same function as the [All] key.
Dist Trigger key with same function as the [Dist] key.
User Key
Light/Level/HT
Transfer/Offset/
Code/Dist.Unit/
Angle Unit/ Hidden
Pt/Delete Rec./
Tracking/Check Tie/
Settings
One function from the Function menu. Customers can
designate the [USER] key according the using frequency
and habit.
V-Setting
Zenith/ Horizon/
V - (%)
The “0” orientation of the vertical circle can be either
selected for the zenith, the horizontal plane or in %.
 Zenith: Zenith=0°; Horizon=90°
 Horizon: Zenith=90°; Horizon=0°
 V-(%): 45°=100%; Horizon=0°
If the V-% value increases rapidly and exceed 300%,
it displays as “--.--%”.
Tilt Crn.
1- axis / OFF
²OFF： Tilt compensation is switched off.
²1-axis V-angle relate to the plumb line.
If the instrument is set on an unstable base (e.g. shaking
platform, ship, etc.) the compensator should be switched
off. This avoids the compensator drifting out of its
measuring range and interrupting the measuring process by
indicating an error.
The compensator setting remains active even after the
instrument is switched off.
Coll Crn.
ON/OFF
²ON : HZ Collimation is switched on.
²OFF: HZ Collimation is switched off.
If option “Coll Crn.” is active, each measured HZ angle is
corrected.
For normal operation, the HZ Collimation remains
switched on.
See “10. Check and Adjust” for detailed instruction.
Sector Beep
ON/OFF
² ON: Sector Beep sounds at right angles (0°, 90°, 180°,
270°, or 0, 100, 200, 300 gon)
²OFF: Sector Beep is switched off.
