STONEX R2
131
Soft Keys:
PREV [F1]: Displays the previous point data.
NEXT [F2]: Displays the next point data.
If the present data is at the end of horizontal alignment, press [NEXT] to return to the
alignment main screen, and it means to add a new alignment data.
SEARCH [F3]: Searches for data. When pressing this key, the program will require user
to insert a chainage. Then press [ENT], and the data of the chainage will be displayed.
PAGE [F4]: Goes to next page (Page 2).
START [F1]：Goes to the beginning of the file, and displays the first alignment data.
LAST [F2]：Goes to the end of the file, and displays the last alignment data.
It is possible to edit data by using the function keys above. After entering the data to be
edited, press [ENT] to record the edited data and enter into the inputting screen of next
point. To quit without saving data, press [ESC].
OPERATIONAL STEPS：
OPERATIONAL STEPS
OPERATION
DISPLAY
① Use soft keypad below the screen,
press [PREV] or [NEXT] to find out
the alignment data needed to edit.
User may also press [SEARCH] to
search for the data needed to edit. In
“Find HZ Alignment” dialog, input the
chainage of alignment data needed to
edit, and press [ENT].
[F1]
or[F2]
[F3]
+
Input chain
[SEARCH] ：
Define HZ AL 16/16
Type： POINT
X/N ： 100.000 m
Y/E ： 100.000 m
Radius： 20.000 m
A1 ： 80.000 m
A2 ： 80.000 m
PREV NEXT SEARCH ↓
START LAST DELETE ↓
Find HZ Alignment
Chain. ---.--- m
OK
【Define HZ AL】 2/1
Type： POINT
X/N ： 100.000 m
Y/E ： 100.000 m
Radius： 20.000 m
A1 ： 80.000 m
A2 ： 80.000 m
PREV NEXT SEARCH ↓
START LAST DELETE ↓
