STONEX R2 User Manual

STONEX R2
57
1. E, N, H of Hidden Point
2. Rod Length
3. Distance R1-R2
OPERATIONAL STEPS
OPEATION
DISPLAY
① Press [FNC] to enter into the
Function menu. Press [PAGE] to turn
to Page 2.
[FNC]
+
[PAGE]
【Function】 2/4
F1 Height Transform (5)
F2 Hidden Point (6)
F3 Free-Coding (7)
F4 Check Tie (8)
②Press [F2] to enter into the Hidden
Point function.
[F2]
【Hidden Point】
Meas first prism!
PtID： ---.---
HZ： 0°00′00″
V： 87°40′00″ Ⅰ
： ---.--- m Mem.
All DIST RECORD RDD/ED
③ Press [F4] (ROD/ED) to set the
total length of the rod, the distance
between R1 and R2, and the
measurement toleration ‴ 1). After
entering one setting, press [ENT] to
move to the next item. Press [F4] to
return to Hidden Point menu after
finishing all the settings.
[F4]
【Rod Length Settings】
Rod Length： ---.---
Dist R1-R2： ---.---
Meas. Tol ： ---.---
OK
④ Enter the point ID of the first
reflector, collimate the reflector and
press [F1](All) or [F2] (DIST) +
[F3](RECORD) to start measurement.
Input PtID1
+
[F1]
Or[F2]
+
[F3]
【Hidden Point】
Meas first prism!
Pt. ID： 1
HZ： 0°00′00″
V ： 87°40′00″ Ⅰ
： ---.--- m Mem.
All DIST SEARCH ROD/ED
⑤ Enter the point ID of the second
reflector, collimate the reflector and
press [F1](All) or [F2] (DIST) +
[F3](RECORD) to start measurement.
Input PtID2
+
[F1]
Or[F2]
+
[F3]
【Hidden Point】
Meas second prism!
Pt. ID： 1
HZ： 0°00′00″
V ： 87°40′00″ Ⅰ
： ---.--- m Mem.
All DIST SEARCH ROD/ED
