STONEX R2 User Manual

STONEX R2
66
②In Setting Station menu, press [F2]
(LIST)
[F2]
Setting Station
Input Station PtID!
Stn Pt: --- --- ---
SEARCH LIST ENH
③ Data of all known points and
measured points will be displayed.
【Point Search】
12 Known
12 Meas.
12 Meas.
12 Meas.
VIEW ENH JOB OK
④Press navigation key to select the
needed point.
VIEW: to view the coordinate
information of the point.
ENH: to input coordinate data in the
job.
JOB: to select data from other job.
VIEW ：
ENH：
JOB：
【Pt Search Coord View】
Pt. ID： 56
X /N： 155.301m
Y/E： 152.361m
H/Z： 129.569m
Date: 2011.06.17
Time: 14:52:06
Start Last OK
Coord Input
Job A:\1.PTS
Pt. ID： ----.---- *
X/N ： ----.---- m
Y /E ： ----.---- m
H/E ： ----.---- m
BACK Save
【Point Search】
Job : 1
Pt. ID: *
More Job
Select job / input Pt Coord
FIND 0SET ENH LIST
⑤ After selecting the needed point,
press [F4] (OK) to enter into INS.Ht
inserting menu.
[F4]
Input
instrument
height
+[ENT] [F4]
Setting Station
Input INS.HT!
INS.Ht: 1.000 m
PtID OK
