Gearbox
g315870
Figure142
1.PTOguard6.Capscrew(4each)
11.Pulley
2.Spacer(2each)7.Gearboxbracket–right
12.Gearboxbracket–left
3.Shoulderscrew(2each)8.Gearbox13.Capscrew(4each)
4.Dipstick/breather9.Squarekey
5.Copperwasher10.Setscrew(2each)
RemovingtheGearbox
WARNING
DonotstarttheengineandengagethePTOswitchwhenthePTO
shaftisdisconnectedfromthecuttingunit.Ifyoustarttheengine
andthePTOshaftisallowedtorotate,seriouspersonalinjuryand
machinedamagecouldresult.
IfthePTOshaftisdisconnectedfromthecuttingunit,disconnect
thePTOelectricclutchelectricalconnector.
RefertoFigure142forthisprocedure.
1.Removethecuttingunitfromthemachine;refertothecuttingunitOperator’s
Manual.
2.Removethebeltcoversfromthecuttingunit.
