ENGINE
4-65TX525 Service Manual Rev. 000
9. Using3/4”and1/2”sockets,removethe7boltsand
nutssecuringtherearframecovertotheframeand
fueltankbracket.Removetherearframecover(Fig.
0316).
Fig 0316 PICT-5381
8. Usinga3/8”socket,removethe6screwsthatse-
curetheleftandrightrearcoversupportpanelsto
thetowerassembly(3screwsperpanel).Remove
thepanels(Fig.0315).
Fig 0315 PICT-4454
10. Removethefueltankbracket(Fig.0317).
Fig 0317 PICT-5625
11. Disconnectthetwowires(blackandorange)from
thefuelsendingunitlocatedonthetopofthefuel
tank(Fig.0318).
Fig 0318 PICT-4262a
