ENGINE
4-73TX525 Service Manual Rev. 000
44. Usinga3/8”socket,loosenthehoseclampsecuring
theradiatorhosetotheengineblock(Fig.0346).
Fig 0346 PICT-5399
45. Slidetheradiatorhoseofftheengineblockinlet(Fig.
0347).
Fig 0347 PICT-5400
46. Carefullyremovetheradiatorandoilcooleras-
sembly(Fig.0348).
Fig 0348 PICT-5402
47. Captheradiatorhosesandangessothatdebris
doesnotenterthesystem.
48. Usinga3/8”socket,loosenthehoseclampsecuring
theairintakehosetotheengineintake(Fig.0349).
Fig 0349 PICT-5405
