ENGINE
4-76 Rev. 000 TX525 Service Manual
57. Removethehairpincotterfromthehoodrod(Fig.
0358).
Fig 0358 PICT-5417
58. Removethehoodrod(Fig.0359).
Fig 0359 PICT-5418
59. Usinga3/16”Allenwrench,removethetop2
screws.Usinga1/2”socket,removethebottom2
screwssecuringtheheatshieldtothetower(Fig.
0360).
Fig 0360 PICT-5419a
60. Removetheheatshield(Fig.0361).
Fig 0361 PICT-5421
