Toro TX525 - Page 130

ENGINE
4-77TX525 Service Manual Rev. 000
61. Usingaspringtool(Torop/n92-5771),unhookthe
idlerspringfromthespringpostonthetower(Fig.
0362).
Fig 0362 PICT-5422
62. Removethedrivebeltfromaroundthepulleys(Fig.
0363).
Fig 0363 PICT-5423
63. Disconnecttheharnessterminalfromthewater
temperaturesensor(Fig.0364).
Fig 0364 PICT-5429
64. UsingaPhillipsscrewdriver,disconnecttheharness
terminalfromtheengineoilpressuresensor(Fig.
0365).
Fig 0365 PICT-5432
