ENGINE
4-78 Rev. 000 TX525 Service Manual
65. Slidethebootoffthealternatorconnection.Usinga
10mmsocket,removethenutandwashersecuring
theharnessterminaltothealternator(Fig.0366).
Fig 0366 PICT-5436
66. Removetheharnessterminalfromthealternator
(Fig.0367).
Fig 0367 PICT-5437a
67. Disconnecttheharnessconnectorfromthealter-
nator(Fig.0368).
Fig 0368 PICT-5439
68. Unplugtheharnessconnectorfromthe.08mm
(blue)fusiblelinkwire(Fig.0369).
Fig 0369 PICT-5444
