ENGINE
4-79TX525 Service Manual Rev. 000
69. Slidetheredbootoffthestarterterminal.Using
a12mmsocket,removethenutfromthestarter
terminal(Fig.0370).
Fig 0370 PICT-5446
70. Removethepositivebatterycablefromthestarter
terminal(Fig.0371).
Fig 0371 PICT-5447
71. Removethe2.0mm(grey)fusiblelinkterminalfrom
thestarterterminal(Fig.0372).
Fig 0372 PICT-5448
72. Removethebluespadeconnectorfromthestarter
terminal(Fig.0373).
Fig 0373 PICT-5449
