Toro TX525 - Page 134

ENGINE
4-81TX525 Service Manual Rev. 000
77. Loosentheswivelclampsecuringthethrottlecable
tothethrottlecontrolbracket(Fig.0378).
Fig 0378 PICT-5465
78. Movethethrottlecontroltoapproximately3/4throttle
untilthethrottlecableslidesoutoftheswivelclamp
(Fig.0379).
Fig 0379 PICT-5466
79. Usinga10mmsocket,removethe2boltssecuring
thethrottlebrackettotheengine(Fig.0380).
Fig 0380 PICT-5467
80. Movethethrottlebracketassemblyawayfromthe
engine(Fig.0381).
Fig 0381 PICT-5468
