ENGINE
4-82 Rev. 000 TX525 Service Manual
81. Slidethehoseclampbackfromthefuellinewhere
itconnectstothefuelinjectionpump.Slidethefuel
lineoff(Fig.0382).
Fig 0382 PICT-5470
82. Slidethehoseclampbackfromthefuellinewhere
itconnectstothefuelinjector.Slidethefuellineoff
(Fig.0383).
Fig 0383 PICT-5472
83. Usinga1/2”socket,removethetopboltandnutand
thenutfromthebottomboltthatsecuresthefuel
pumpbrackettothetowerframe(Fig.0384).
Fig 0384 PICT-5473
84. Movethefuelpumpassemblyawayfromtheengine.
Note: 280000501 and higher TX525 serialized
products incorporate a partially revised fuel
delivery system.
270000001-280000500(Fig.0385):
Fig 0385 PICT-5476
