ENGINE
4-89TX525 Service Manual Rev. 000
6. Loosenthe2alternatormountingbolts(Fig.0410).
Fig 0410 PICT-5507
7. Pivotthealternatortowardtheenginetorelievebelt
tension.
8. Usinga13mmsocketanda9/16”wrench,secure
thehexspacerandremovethebottomalternator
mountingbolt,lockwasherandatwasher(Fig.
0411).
A. 12mmsocket(topbolt)
B. 13mmsocket(bottombolt)
Fig 0411 PICT-5510
A
B
9. Removethealternatorbelt(Fig.0412).
Fig 0412 PICT-5514a
10. Removethetopmountingbolt,lockwasher,belt
guardandalternator(Fig.0413).
Fig 0413 PICT-5515a
