15. Securethefanmountspacer.Usinga1/4”Allen
wrench,removethe3boltssecuringthefanmount
spacertotheenginecoupler(Fig.0418).
Fig 0418 PICT-5524
16. Removethefanmountspacer(Fig.0419).
Fig 0419 PICT-5525
17. Usinga1-1/8”wrench,removetheoildraintting
fromtheoilpan(Fig.0420andFig.0421).
Note: There is a 90 degree angle oil drain tting and
a straight oil drain tting.
• 90degreeoildraintting:
Fig 0420 PICT-5550a
• straightoildraintting:
Fig 0421 PICT-8773
