ENGINE
4-92 Rev. 000 TX525 Service Manual
18. Usinga10mmsocket,removethe2boltssecuring
theengineshutdownsolenoidbrackettotheengine
(Fig.0422).
Fig 0422 PICT-5531
19. Usinga5mmAllenwrench,removethe2boltsand
lockwasherssecuringtheengineshutdownsolenoid
totheengine(Fig.0423).
Fig 0423 PICT-5532
20. Removetheengineshutdownsolenoidfromthe
engine(Fig.0424).
Fig 0424 PICT-5534
21. Usinga9/16”socketandwrench,removethe2bolts
andnutssecuringtheenginemountplatetotheright
handenginemount(Fig.0425).
Fig 0425 PICT-5536
