Toro TX525 - Page 148

ENGINE
4-95TX525 Service Manual Rev. 000
30. Removethemufermount(Fig.0434).
Fig 0434 PICT-5546a
31. Usinga13mmsocket,removethe4boltssecuring
thetandempump/pumpmountassemblytothe
engine(Fig.0435).
Fig 0435 PICT-5547a
32. Removethetandempump/pumpmountassembly
andcouplerfromtheengine(Fig.0436).
Fig 0436 PICT-5531-2
33. Removethedrivebeltfromtheengine(Fig.0437).
Fig 0437 PICT-5533-2
