ENGINE
4-99TX525 Service Manual Rev. 000
11. Torquethe5boltsto38+4ft-lbs.(51.5+5.4Nm)
(Fig.0450).
Fig 0450 IMG_8090
12. PositiontheISOenginemounttotherighthand
enginemount(Fig.0451).
Fig 0451 PICT-5542
13. Usinga1/2”socket,install2boltssecuringthe
forwardISOenginemounttotherighthandengine
mount(Fig.0452).
Fig 0452 IMG_8093
14. Torquethe2boltsto220+25in-lbs.(24.8+2.8
Nm)(Fig.0453).
Fig 0453 IMG_8092
