35. Usingan7/16”socket,install4boltssecuringthefan
tothefanmountspacer(Fig.0474).
Fig 0474 PICT-5521a
36. Torquethe4boltsto100+10in-lbs.(11.3+1.1Nm)
(Fig.0475).
Fig 0475 PICT-5558a
38. Slidethealternatorcollarintothealternatormount-
ingange(Fig.0477).
Fig 0477 PICT-5559
37. Positionthehexspacerthroughthedipstick.Loose-
lyinstallanutontothehexspacer(Fig.0476).
Fig 0476 PICT-5518
