31. Positionthefanmountspacer(Fig.0470).
Fig 0470 PICT-5525
32. Install3boltssecuringthefanmountspacertothe
enginecoupler(Fig.0471).
Fig 0471 PICT-5523
34. Slidethefanontothefanmountspacer(Fig.0473).
Fig 0473 PICT-5522a
33. Usinga1/4”Allenwrench,torquethe3boltsto19+
2ft-lbs.(25.7+2.7Nm)(Fig.0472).
Fig 0472 PICT-5556
