Toro TX525 - Page 160

ENGINE
4-107TX525 Service Manual Rev. 000
TX525 22319#270000721&higher
 22320#270000886&higher
 22333#270000447&higher
 22334#270000437&higher
Theenginegearcasehousingangeisnotthreaded
(notpictured).
TX525 22319#270000556-270000720
 22320#270000712-270000885
 22333#270000423-270000446
 22334#270000427-270000436
Theenginegearcasehousingangeisnotthreaded
(Fig.0481).
Fig 0481 PICT-9354
43. Withthealternatorbelttensioned,tightenthebottom
alternatormountingbolt(Fig.0483).
Fig 0483 PICT-5510
42. Applytensiontothealternatorbeltandtightenthe
topalternatormountingbolt(Fig.0482).
Fig 0482 PICT-5565
