ENGINE
4-113TX525 Service Manual Rev. 000
11. Usinga9/16”socketandwrench,install2nuts
securingtheenginemountplatetothelefthand
enginemount(Fig.0504).
Fig 0504 PICT-5487
12. Torquethe2boltsto30+3ft-lbs.(41+4Nm)(Fig.
0505).
Fig 0505 PICT-5577
13. Positiontheengineintothemainframealigningthe
mountingholesontheenginemountplateswiththe
mountingholesinthemainframe.
14. Removetheenginehoistfromtheengine.
15. Usinga9/16”socketandwrench,looselyinstallthe
rear2boltsandnutssecuringthelefthandsideof
theengineassemblytothemainframe(Fig.0506).
Fig 0506 PICT-5484
16. Usinga9/16”socketandwrench,looselyinstallthe
rear2boltsandnutssecuringtherighthandsideof
theengineassemblytothemainframe(Fig.0507).
Fig 0507 PICT-5481
