ENGINE
4-118 Rev. 000 TX525 Service Manual
Fig 0524 PICT-5589
Note: Some TX525 models have a rubberized
R-clamp secured to the top fuel pump mount-
ing bolt. The throttle cable should be routed
through that R-clamp (Fig. 0525).
Fig 0525 PICT-5583a
30. Routethethrottlecabletotheleftoftheheatshield
mountandoverthetopofthefuelpump(Fig.0523
andFig.0524).
Fig 0523 PICT-5588
31. Positionthethrottlebracketassemblyuptothe
mountingsurfaceontheengine(Fig.0526).
Fig 0526 PICT-5468
