32. Usinga10mmsocket,install2boltssecuringthe
throttlebrackettotheengine.Torquethe2boltsto
7.23to8.32ft-lbs.(9.8to11.3Nm)(Fig.0527).
Fig 0527 PICT-5467
33. Withthethrottlecontrolinthefastposition,liftupthe
throttlebracketswivelclamp.Alignthethrottlecable
andtheswivelclamphole.Movethethrottlecontrol
levertotheslowpositionsothatthethrottlecable
insertsthroughtheswivelclamp(Fig.0528).
Fig 0528 PICT-5586a
34. Tightentheswivelclampsecuringthethrottlecable
tothethrottlecontrolbracket(Fig.0529).Adjustthe
throttlecable.Referto“ThrottleCableAdjustment”
onpage4-142.
Fig 0529 PICT-5465
35. Slidethestarwasher,negativebatterycableterm-
inalandharnessgroundterminalontoabolt(Fig.
0530).
Fig 0530 PICT-5462
