ENGINE
4-120 Rev. 000 TX525 Service Manual
37. Plugtheharnessconnectorintotheengineshut-
downsolenoidconnector(Fig.0532).
Fig 0532 PICT-5459
38. Routetheglowplugharnesscablebehindthefuel
line,underthesolenoidconnectorandunderthefuel
injectorlines(Fig.0533).
Fig 0533 PICT-5590
36. Usinga13mmsocket,installtheboltsecuringthe
starwasher,negativebatterycableandharness
terminaltothefuelinjectionpump(Fig.0531).
Fig 0531 PICT-5460
39. Slidetheglowplugharnessterminalontothecenter
glowplugterminal(Fig.0534).
Fig 0534 PICT-5457
