ENGINE
4-121TX525 Service Manual Rev. 000
40. Usinga7mmsocket,installanutsecuringthe
harnessterminaltotheglowplug(Fig.0535).
Fig 0535 PICT-5456
41. Positionthefuelpumpconnectortotheengineside
ofthefuelpumpmountingbracket(Fig.0536).
Fig 0536 PICT-5591
42. Routethefueltankharnesswiresbacktotherear
ofthemachinebetweenthetowerandthehydraulic
ltertotankline(Fig.0537).
Fig 0537 PICT-5594
43. Installthebluespadeconnectorontothestarter
terminal(Fig.0538).
Fig 0538 PICT-5449
