ENGINE
4-155TX525 Service Manual Rev. 000
10. Removethebrushholderfromthealternator
assembly(Fig.0667).
Fig 0667 PICT-8255
11. Removethe3screwssecuringtheregulatoras-
semblytothealternator(Fig.0668).
Fig 0668 PICT-8180
12. Removetheregulatorassemblyfromthealternator
(Fig.0669).
Fig 0669 PICT-8181
13. Removethe4screwssecuringtherectiertothe
alternatorassembly(Fig.0670).
Fig 0670 PICT-8182
