ENGINE
4-165TX525 Service Manual Rev. 000
6. Installthebearingintothedriveendframe(Fig.
0702andFig.0703).
Fig 0702 PICT-8233
Fig 0703 PICT-8234a
7. Positiontheretainerplateintothedriveendframe
overthebearingwiththeretainerplatetabsfacing
towardthebearing(Fig.0704).
Fig 0704 PICT-8236a
8. UsingaPhilipsscrewdriver,install4screwsto
securetheretainerplatetotheinsideofthedrive
endframe(Fig.0705).
Fig 0705 PICT-8238
