Toro TX525 - Page 220

ENGINE
4-167TX525 Service Manual Rev. 000
Fig 0710 PICT-8245
12. Coileachofthe4statorleadsthatarethreaded
throughtherectiersothattheyeachcoilaroundthe
threadedscrewholes(Fig.0711).
11. Positiontherectierontothealternatorassemblyso
the4statorleadsfeedthroughthe4holesthatare
nexttoeachofthescrewholesintherectier(Fig.
0709andFig.0710).
Fig 0711 PICT-8247
Fig 0709 PICT-8243
13. Install4screwssecuringthestatorcoilleadsand
rectiertothealternatorassembly(Fig.0712).
Fig 0712 PICT-8249a
