ENGINE
4-176 Rev. 000 TX525 Service Manual
20. Removethecollarfromtheshaft(Fig.0744). 22. Whilesupportingtheshaft,removethesnapring
(Fig.0746).
Fig 0744 PICT-8107a
Fig 0746 PICT-8056a
23. Whilesupportingtheshaft,removethewasherfrom
theshaft(Fig.0747).
21. Removetheclutchassemblyfromtheshaft(Fig.
0745).
Fig 0747 PICT-8057a
Fig 0745 PICT-8051a
