ENGINE
4-181TX525 Service Manual Rev. 000
6. Slidetheclutchassemblyontotheshaft(Fig.0762). 8. Installacirclipintothegrooveoftheshaftassembly
(Fig.0764).
Fig 0762 PICT-8105a
Fig 0764 PICT-8108
9. Pressthecollarontotheinstalledcirclip(Fig.0765).
7. Slidethecollarontotheshaft(Fig.0763).
Fig 0765 PICT-8110
Fig 0763 PICT-8107a
