ENGINE
4-182 Rev. 000 TX525 Service Manual
10. Removetheshaftassemblyfromtheviseandclamp
thestarterhousingintothevise.
11. Slidetheleverontotheshaftassemblybetweenthe
washerandtheclutch(Fig.0766).
Note: There is a notch in the bottom of the bearing
assembly (Fig. 0768) that ts into the groove
inside the housing (Fig. 0769). The notch
and groove must be lined up to fully seat the
bearing assembly in the housing.
Fig 0766 PICT-8112a
Fig 0768 PICT-8116
12. Inserttheshaft/leverassemblyintothestarter
housing(Fig.0767).
Fig 0769 PICT-8115
Fig 0767 PICT-8114
