ENGINE
4-183TX525 Service Manual Rev. 000
13. Applylithiumgreasetothegearteethandthe3gear
postsontheshaftassembly(Fig.0770).
15. Applyalightcoatoflithiumgreasetothe3gears
(Fig.0772).
Fig 0770 PICT-8117 Fig 0772 PICT-8121
16. Installtheplateintothebearingassembly(Fig.
0773).
Note: There is a tab on the plate that must align with
the groove inside the bearing.
14. Install3gearsontotheshaftassemblygearposts
(Fig.0771).
Fig 0773 PICT-8124a
Fig 0771 PICT-8119
