17. Slidethearmatureassemblyintothestarteras-
sembly(Fig.0774).
19. Pullbackonthebrushholdersprings.Slidethe
brushesoutwardsothatthespringsareholdingthe
brushesout(Fig.0776).
Fig 0774 PICT-8125a
Fig 0776 PICT-8129a
20. Slidethebrushholderontotheyokeassembly.The
openbrushslotsshouldlineupwiththepositive
brushesontheyoke(Fig.0777).
A. Spring B. Brush
18. Slidetheyokeassemblyontothearmature(Fig.
0775).
Note: There is a tab on the yoke that lines up with a
groove in the armature.
Fig 0777 PICT-8130
Fig 0775 PICT-8126a
A
B
