29. Slidethestarterwireontotheshortterminalonthe
magneticswitch(Fig.0787).
Fig 0787 PICT-8159
30. Slidethejumperwireringterminalontotheshort
terminalonthemagneticswitch(Fig.0788).
28. Usinga10mmsocket,install2nutsontothemag-
neticswitchmountingboltssecuringittothestarter
(Fig.0786).
Fig 0788 PICT-8163
Fig 0786 PICT-8158a
31. Usinga12mmsocket,installanutontothemag-
neticswitchshortterminaltosecurethewires(Fig.
0789).
Fig 0789 PICT-8164
