HYDRAULIC SYSTEM
6-15TX525 Service Manual Rev. 000
3. Apply thread locking compound to the spacer
mounting bolt (Fig. 0885).
Fig 0885 PICT-4916a
4. Using a 7/16” wrench, install the hio spacer onto
valve cap bolt (Fig. 0886).
Fig 0886 PICT-1777a
5. Slide the spring over the hio spacer and hook the
spring under valve cap screw (Fig. 0887).
Fig 0887 PICT-1775a
6. Install the handle onto the hio spacer and hook the
spring onto the handle (Fig. 0888).
Fig 0888 PICT-1774a
