HYDRAULIC SYSTEM
6-16 Rev. 000 TX525 Service Manual
7. Using two 7/16” wrenches, install the top washer
and nut securing the handle to the hio spacer (Fig.
0889).
Fig 0889 PICT-1779a
8. Lower the valve into the frame (Fig. 0890).
Fig 0890 PICT-4913a
9. Using a 1/2” socket and wrench, install 2 mounting
bolts and nuts securing the valve to the control panel
frame (Fig. 0891).
Fig 0891 PICT-4912
10. Plug the safety switch into the wire harness (Fig.
0892).
Fig 0892 PICT-4910
