ENGINE
4-2 Rev. 000 TX525 Service Manual
7. Slidethegrillassemblyforward(Fig.0083). 9. Removethegrillassemblytakingcarenottodam-
agethehydraulictankbreatherhose(Fig.0085).
Fig 0083 PICT-4955
Fig 0085 PICT-4961
8. Removethe2boltsandnutssecuringtheoverow
tankbrackettothegrillassembly(Fig.0084).
Fig 0084 PICT-4959
Fig 0082 PICT-4953
6. Removethe4boltssecuringthegrillassemblyto
theframe(Fig.0082).
