23. Slidethe2radiatorhosesoffthelefthandsideofthe
radiator(Fig.0094).
25. Removetheradiator/oilcoolerassemblyfromthe
frame(Fig.0096).
Fig 0094 PICT-4978
Fig 0096 PICT-4980
26. Captheinletandoutletangesandttingssothat
debrisdoesnotenterintothecoolingsystem.
27. Torepairorreplaceonlytheoilcooler,continueon
to“OilCoolerRemoval”.Torepairorreplacethe
radiator,referto“RadiatorRemoval”onpage4-10.
24. Loosenthehoseclampsecuringtheradiatorhoseto
therighthandsideoftheradiator.Slidetheradiator
hoseofftherighthandsideoftheradiator(Fig.
0095).
Fig 0095 PICT-4979
