ENGINE
4-33TX525 Service Manual Rev. 000
3. Routethealternatorbeltaroundthealternatorpulley
(Fig.0196).
Fig 0196 PICT-5178
4. Positionthealternatorbeltguarduptotheslotted
bracket(Fig.0197).
6. Looselyinstallthealternatormountingbolt,lock
washerandwasherthroughthebeltguard,alterna-
tor,collerandintothealternatormountingange
(Fig.0199).
Fig 0197 PICT-5177
Fig 0199 PICT-5176
5. Usinga12mmsocket,looselyinstallthealternator
belttensioningboltandlockwasher(Fig.0198).
Fig 0198 PICT-5166
