ENGINE
4-34 Rev. 000 TX525 Service Manual
8. Applytensiontothealternatorbeltandtightenthe
topalternatormountingbolt(Fig.0201).
Fig 0201 PICT-5565
7. Positionthethreadedhexspacerintothedipstick
bracketandalignitwiththealternatormounting
ange(Fig.0200).
Fig 0200 PICT-5175
9. Usinga13mmsocketanda9/16”wrench,tighten
thealternatormountingbolt,lockwasherandat
washersecuringthealternatortotheengineblock
andthreadedhexspacer(Fig.0202).
Fig 0202 PICT-5188
10. Usinga12mmsocket,installaangenutontothe
hexspacersecuringittothedipstick(Fig.0203).
Fig 0203 PICT-5170
