ENGINE
4-35TX525 Service Manual Rev. 000
11. Tensionthealternatorbelt.Referto“Alternator/Fan
Belt”onpage3-26.
12. Plugtheharnessconnectorintothealternator(Fig.
0204).
Fig 0204 PICT-5165
13. Slidethepositivebatterycableterminalontothe
alternatorterminal(Fig.0205).
Fig 0205 PICT-5164
14. Slideawasherontothealternatorterminal(Fig.
0206).
Fig 0206 PICT-5162
15. Usinga10mmsocket,installanutsecuringthe
positivebatterycabletothealternatorterminal(Fig.
0207).Slidethebootontotheterminal.
Fig 0207 PICT-5161
